Many PS5 owners buy a high-refresh-rate monitor expecting smooth 120Hz gameplay only to find themselves stuck at 60Hz. The good news is that this issue is usually fixable through a combination of correct system settings, hardware verification, and specific monitor adjustments. By following a structured troubleshooting order—starting with PS5 settings, then hardware, monitor OSD, and game-specific options—you can quickly determine whether the problem is a simple configuration issue or a compatibility limitation.
Why Is Your PS5 Stuck at 60Hz? Common 120Hz Failures
Owning a 144Hz or 240Hz monitor does not automatically deliver 120Hz output from the PS5. The console and game must both be configured to use the higher refresh rate, and the monitor must properly handshake with the PS5 over HDMI. This creates a "double gate" where both system-level and in-game settings need attention.
The root cause often falls into three categories: incorrect PS5 video output settings, insufficient hardware bandwidth from the cable or port, or monitor OSD features that block the 120Hz timing. Identifying which layer is failing helps you avoid unnecessary upgrades. For most users with a modern gaming monitor, the fix lies in settings rather than new hardware.
Configuring Your PS5 for 120Hz Output
Start troubleshooting at the console level. Navigate to Settings > Screen and Video > Video Output. Set 120Hz Output to Automatic so the PS5 can switch to 120Hz when a supported game and display allow it. This official PlayStation guide confirms that keeping the setting on Automatic is required for high-refresh gameplay.
Also set Resolution to Automatic (or a supported value like 1080p, 1440p, or 2160p). After applying changes, check the Current Video Output Information screen to confirm the active refresh rate and resolution. Many users see immediate improvement here before touching the monitor.
If the output still shows 60Hz after these changes, the issue likely lies in hardware compatibility or monitor settings rather than the console itself.
Enabling Performance Mode at the System Level
Many games check the system-wide preset before offering high-frame-rate options. Go to Settings > Saved Data and Game/App Settings > Game Presets and select Performance Mode or Performance Mode or Resolution Mode. This tells supported titles to prioritize frame rate over graphical fidelity.
PlayStation's picture and sound troubleshooting page notes that this global preset is essential for unlocking higher frame rates in compatible games. Keep in mind that Performance Mode does not force 120Hz in every title—it simply removes one common barrier.
Hardware Check: HDMI 2.1 vs HDMI 2.0 Requirements
4K at 120Hz requires an HDMI 2.1 port and sufficient bandwidth. The stock PS5 cable is rated as Ultra High Speed HDMI and supports the full HDMI 2.1 specification, so replacing it is rarely necessary unless the cable is damaged or too short.
HDMI 2.0 ports can support 120Hz at 1080p or 1440p on monitors that provide the correct timings, but they lack the bandwidth for 4K at 120Hz and do not support Variable Refresh Rate (VRR) on the PS5. Success at these lower resolutions depends on the monitor's internal timing profiles.
The chart below visualizes these practical limits:
PS5 HDMI 2.0 vs 2.1: 120Hz and VRR Fit by Resolution
Decision guide for whether HDMI 2.0 is enough or HDMI 2.1 is needed for PS5 120Hz play, with VRR availability shown as a separate capability.
View chart data
| Category | HDMI 2.0 | HDMI 2.1 |
|---|---|---|
| 1080p @ 120Hz | 1.0 | 1.0 |
| 1440p @ 120Hz | 1.0 | 1.0 |
| 4K @ 120Hz | 0.0 | 1.0 |
| VRR | 0.0 | 1.0 |
PlayStation's official documentation confirms that 4K at 120Hz needs HDMI 2.1. If your monitor only has HDMI 2.0 ports, target 1080p or 1440p at 120Hz rather than forcing 4K.
Our How to Connect Your PS5 or Xbox Series X to a Gaming Monitor provides additional tips on cable and port selection for consoles.
Troubleshooting Monitor OSD Settings and Blockers
Monitor on-screen display (OSD) settings frequently block the 120Hz handshake, especially on HDMI 2.0 panels. A common fix is to disable FreeSync or Adaptive Sync in the monitor menu, as this feature can interfere with the PS5's timing detection on non-HDMI 2.1 displays. PlayStation's VRR announcement notes that VRR is limited to HDMI 2.1 compatible displays, and disabling these features often resolves the issue.
Turn off any Overclock (OC) or extended refresh modes—the PS5 handshake is most reliable at the monitor's native refresh rate. Some monitors default connected ports to HDMI 1.4 compatibility; manually select HDMI 2.0 or 2.1 in the OSD if available. In rare cases, temporarily disabling HDR can stabilize the connection on budget panels.
These OSD changes often resolve the problem without buying new hardware. Our guide on G-Sync vs. FreeSync: Which One is Better for Gaming in 2025? explains how adaptive sync features interact with different devices.
Verifying Game-Level 120Hz Activation
Even with perfect system and hardware setup, 120Hz is not universal. It only activates in supported games such as Call of Duty, Fortnite, or other titles with explicit high-frame-rate modes. Check the in-game Video or Graphics menu for a 120Hz Mode, Performance Mode, or High Frame Rate toggle.
If the option appears grayed out, return to the system Performance Mode preset and confirm your resolution is not set too high for the game. Many users complete all console and monitor steps only to miss this final in-game gate.
What to Do if 120Hz Still Does Not Appear
When standard steps fail, simplify the connection. Remove any HDMI switchers, splitters, or capture cards that can strip timing metadata. Perform a full power cycle: unplug the PS5, monitor, and power cables for at least 30 seconds, then reconnect and test again.
As a last resort, some users employ an EDID emulator to force the desired timings, though this is an advanced step. If your monitor simply lacks the required CTA-861 video timings, it may never reliably support PS5 120Hz output.
Consider upgrading to a monitor confirmed for console use. Models like the KTC 27" 4K 160Hz/320Hz 90W Gaming Monitor | H27P6 offer HDMI 2.1 ports and strong console compatibility. Browse our full Gaming Monitor collection or check 4K Monitor options for high-refresh 4K panels.
For more on refresh rate benefits, read Which Refresh Rate Is Best for Gaming: 60Hz, 144Hz, or 240Hz? and 4K for Competitive Gaming: A Performance Advantage or Disadvantage?.
FAQs
Can I get 120Hz on PS5 using only HDMI 2.0? Yes, at 1080p or 1440p on monitors that support the necessary video timings, but 4K at 120Hz and VRR are not possible.
Why does my 144Hz monitor only show 60Hz options on PS5? The monitor OSD may have FreeSync enabled, be set to an overclock mode, or lack proper CTA-861 timings that the PS5 expects.
Does enabling Performance Mode on PS5 guarantee 120fps? No. It sets a global preference, but individual games must still offer and be manually set to a 120Hz or high-frame-rate mode.
Should I disable VRR or FreeSync to get 120Hz? On many HDMI 2.0 monitors, yes—disabling these features often allows the PS5 to detect and use 120Hz output.
What resolution should I use for the smoothest 120Hz experience on PS5? 1080p or 1440p typically delivers the most consistent results, especially if your monitor or cable is limited to HDMI 2.0.
Will a different HDMI cable fix my 120Hz problem? Only if you are using a damaged or very old cable. The included PS5 Ultra High Speed cable is sufficient for most setups.
Are all high-refresh-rate monitors compatible with PS5 120Hz? No. Monitors designed primarily for PC use may require specific OSD changes or may never fully support the console's timing requirements.
